    New 500-1500 Kg Load Capacity Electric Pallet Lift Stacker Electric Stacker With Paper Roll Clamp

    Ask Lasest Price
    Brand Name : KAD
    Model Number : RD070BJ-15
    Certification : CE
    Price : $4000-$6000 /unit
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 50units/month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    New 500-1500 Kg Load Capacity Electric Pallet Lift Stacker Electric Stacker With Paper Roll Clamp

    Product Description

    New 500-1500 kg load capacity electric pallet lift stacker electric stacker with paper roll clamp

    Electric paper roll stackers are widely used in paper industry, packaging industry, printing industry, textile industry handling, suitable for paper tube, carpet, fabric, cable, wood, steel coil, rope, tyre, film rolls or all industries round shape warehouse workshop goods handling, shifting, stacking, electric turning and other work. Holding clip type: cylindrical, oil drum type, shaped, etc., the rotation mode for 90 degrees, 180 degrees and 360 degrees. With the help of the unique clamping, side shifting and rotating functions of the attachments, the goods can be transported, stacked, loaded or unloaded in a safer way, thus minimising the loss of goods.

    New 500-1500 Kg Load Capacity Electric Pallet Lift Stacker Electric Stacker With Paper Roll Clamp

    New 500-1500 Kg Load Capacity Electric Pallet Lift Stacker Electric Stacker With Paper Roll Clamp

    Main Features

    1.It is suitable for holding goods, rotating, raising and placing.

    2.Suitable for cylindrical goods such as paper drum, paper roll, cloth roll, cable, cable, tire, oil drum, wood, etc.

    3.It can rotate 180 degrees or 360 degrees electrically.


    4.Clamping diameter and lifting height can be designed according to customer's goods and requirements.

    Specification
    Rated load
    kg
    500/1000/1500
    Max height of clamp
    mm
    1500/3000/customized
    Min height of clamp
    mm
    100
    Load center
    mm
    500
    Operation way
    Electric moving, lifting, rotating, graping
    Turning radius
    mm
    1520
    Aisle width
    mm
    2500
    Length
    mm
    1900
    Width
    mm
    810
    Height
    mm
    1900
    Mast
    1-stage/2 stage
    Adjustable extent of clamp
    mm
    700-1200
    Rotation angle
    °
    90/180/360
    Running speed (load/unload)
    km/h
    4.3/4.5
    Hoisting speed(load/unload)
    mm/s
    110/160
    Descent speed(load/unload)
    mm/s
    150/130
    Climbing capability
    (load/unload)
    %
    5/8
    Braking mode
    Electronic brake
    Tyres,material
    Pu
    Hydraulic motor
    kw
    2.5kw
    Battery
    v/ah
    24/80Ah
    Charger
    v/a
    24v/30
    Weight
    kg
    1000

    The significance of the use of forklift attachments:

    1.High productivity, low operating costs.

    Mechanized handling than the traditional manpower handling operations work short, while reducing the income and cost of labour, and improve the efficiency. In the same handling cycle, the number of forklift initiatives significantly lower, forklift corresponding tyres, transmission gears, fuel consumption, etc. are also reduced accordingly, the operating costs are also reduced accordingly.

    2.Safe and reliable operation reduces the accident rate.

    Forklift attachments designed and consumed by professional forklift attachments manufacturers for different industrial conditions are designed with safety devices, so that the goods clamped (or forked) are not easy to slide down in abnormal conditions, such as the pressure-retaining installation of clamping attachments (the oil pipe bursts when the goods are loaded, and the hydraulic fracture maintains the pressure so that the goods will not slide down); the end buffer installation of sidetransferring attachments, etc, which reduces the rate of accidents.

    3.Little loss of goods.

    With the help of the fixtures unique clamping, side shift, rotation and other functions, the goods can be more safely transported or stacked high or loading and unloading, and thus minimise the level of loss of goods. The use of attachments also reduces the frequency of pallet use (e.g. no pallet handling operations), its corresponding marketing and maintenance costs.

    The above points are the benefits of using forklift attachments, so it is more appropriate to use forklift attachments if necessary.
